FLAMCO SUPASTOR 200L DIRECT Unvented Cylinder with 3 x 3kW Immersion Heaters

FREE DELIVERY TO UK MAINLAND

Includes Expansion Vessel and T&P Relief Valve

Current stock: 12pcs

Flamco

Model:
200L SUPASTOR DIRECT

Type:
22.200.DI.01

Rated storage volume:
200 L

Max. design pressure:
800 kPa (8 bar)

Max. pressure supplied to PRV:
2500 kPa (25 bar)

Set pressure PRV:
300 kPa (3 bar)

Pre-charge expansion vessel:
300 kPa (3 bar)

Operating temp non-self-resetting thermostat:
80 °C

Required flow temperature:
80 °C

T & P valve part number:
FCTP 73X75-7

Immersion heater:
3x 3kW / 230–240 V~

Standing heat loss:
1.848 kWh / 24 h

Weight (empty / full):
41 kg / 241 kg

Serial number:
22200DI01.190500084

Compliance:
CE

The appliance shall be fitted with a pressure reducing valve within the installation.

This item is currently part of our Special Offers collection.
