JOULE 170L Cyclone Direct Standard C

• Direct cylinders are heated by the Electric Immersion heaters only
• 3kW Incoloy immersions fitted as standard
• Insulation thickness is 50mm
• Compression connections fitted as standard
• Bevelled stat pocket for better fitting
• Metallic grey wipe clean rigid case for premium appearance
• Pre plugged secondary tapping for ease of installation
• All Connections clearly labelled
• Comes complete with unvented kit (see page 14 of installation guide )
• Butt Welded process used throughout
• Robotically welded
• Branded quality components
• All unvented cylinders require a yearly service
• Supplied with a 1 year guarantee from the manufacturer

Joule Cyclone Standard Direct TCEMVD-0170LFD Unvented Cylinder Specifications:

---

Capacity	170 Litre
Height	1310mm
Diameter	540mm
Weight (Empty)	37 Kg
Weight (Full)	207 Kg
Hot Water Volume	170 Litre
Energy Efficiency Class	D
Heat Up Time - Coil	96 Minutes
Annual Electricity Consumption	2830 kWh
Collection	Cyclone
EAN Barcode	5055743504303
Manufacturer Part Number	TCEMVD-0170LFD



Datasheet
